Description
An Impact Mole (otherwise referred to as a soil displacement hammer or an earth piercing tool) is the simplest way of getting a pipe or cable through displaceable soils such as sand, loam and gravel.
Impact moles are a popular non destructive and low-cost trenchless installation method used for the installation of pipes. Impact moles are driven through the ground by compressed air and as a result, require minimal excavation.
If you are looking to hire Impact Moles to help position pipes underground and need a prompt, professional service with competitive rates and fast, reliable delivery then give Site Equipment a call today.
We offer mole hire or purchase for sites across the UK from one of our fully equipped depots.
Benefits of Impact Moles
- Impact Moles are available from 45mm up to the new 180mm size and this easy to use A to B system is ideal for your needs
- Up to 20m in length
- Two small pits, one entry and one exit is all that is required
- The design prevents any real damage and disruption to the area
- Minimal excavation required
- Wide range of towing heads available
- Forward and reverse gear
- Bull nose reverse towing compatible
- Cost effective solution vs other trenchless methods
Impact Mole Accessories
We stock a wide range of impact mole accessories and supply the following as standard with every order:
- Optical Sights (Laser / Standard)
- Safety Launchers with Pins
- Lubricators
- Air Hoses
- Ranging Rod
Additionally, we can supply mole oil & antifreeze mole oil as an optional extra if required.
Common Applications of Impact Moles
Common applications of impact moling equipment are the installation of small diameter pipes including water mains,
sewage pipes, gas pipes and other underground services underneath roads, pavements, railroads and other crossings.
Mole Cable Laying
In addition to pipes, impact moles can also be used for cable moling to lay electric cables, fibre optic cabling and phone cables. An impact mole is sometimes referred to as a cable mole when used for this application.
When choosing your impact mole, always allow an extra 30%.
To ensure there is no friction or drag, it is important that the impact mole is larger than the product. For example, 45mm lays pipes up to 32mm but if you are in doubt, contact the team at Site Equipment Ltd.
FAQs
What is an impact mole?
An impact mole is a device used in trenchless technology for laying pipes, cables and ducts, without the need for continuous trenching.
Why use an impact mole for groundworks?
Using an impact mole for groundworks allows for efficient, less disruptive and cost-effective excavation compared to traditional methods.
How does an impact mole work?
An impact mole works by hammering its way through the soil along the desired path of the pipe or cable, pushing the soil aside to create a tunnel.
What are the benefits of using an impact mole from Site Equipment Limited?
Our impact moles are reliable, durable and designed for optimal performance, ensuring efficient and effective groundworks for your projects.
Is training required to operate an impact mole?
While operating an impact mole is straightforward, proper training is recommended to ensure safe and effective use.
Can I rent an impact mole from Site Equipment Limited?
Yes, we offer rental options for our impact mole equipment. Contact us for more details.
What types of projects can benefit from using an impact mole?
Projects involving pipe or cable laying, such as utility installations, landscaping, and construction, can greatly benefit from using an impact mole.
What is the service life of an impact mole?
The service life of an impact mole can vary depending on usage and maintenance, but with proper care, they can last for many years.
Do you offer support and maintenance for the impact mole?
Yes, we offer comprehensive support and maintenance services for our impact mole equipment.
Where can I use an impact mole in the UK?
Impact moles can be used anywhere in the UK where trenchless technology is permitted and suitable for the ground conditions. We deliver impact moles nationwide.
